PLC 3 - PLC programming & control: setup

Learn to program modules and scale input signals in a PLC as well as set up controllers.

Course content

  • Knowledge of signal conditioning and scaling of analog and digital signals, including AD converters.

  • Configuration and testing of analog input and output modules in a PLC and in an automatic system with digital communication to the PLC.

  • Connects the modules to various types of transmitters and actuators, e.g. proportional valves and motor controllers.

  • Programming and use of the analog input and output signals in the PLC's mathematical function blocks.

In connection with setting up regulators, this means:

  • The participant can adjust simple control loops.

  • The participant has insight into the principles of control loops, e.g. feedback control.

  • The participant adjusts and optimizes simple control loops with a PLC-PID controller.

  • The participant documents the fluctuation process (trend graph).

Equipment and software

PLC: Siemens S7-1200

Software: TIA portal

Target group

The course is for those who will be working with PLC control. It is recommended that you have completed the PLC Basics course or have equivalent qualifications before taking the course.

Course certificate

A course certificate giving competence is issued.

Instructor on the course:

PLC - programmering af PLC & regulering: opsætning amu no: 49025 positive list
PERIODER
days: 5 date: 5/4/2026 - 5/8/2026
amu no: 49025
date: 5/4/2026 - 5/8/2026

teachers on the course

Mikkel Mellergaard

Mikkel Mellergaard is a qualified electrician and electrical installer. He has worked for seven years at Strøm Hansen. Since 2008, Mikkel has taught all subjects within industrial installations.
